  The First Vitrified Diamond Grinding Wheel used in thermal spraying coating in MoreSuperHard

  Vitrified bond and Resin bond, Vitrified bond has longer lifespan and higher efficiency than resin bond

  Used for cylindrical grinding of tungsten carbide coating in thermal spraying industry

  Models: 1A1(Diameter: 100mm-1200mm), 14A1


TAG:  vitrified diamond grinding wheel vitrified bond thermal spraying coating resinbond
Product Details

Applications:

* For tungsten carbide workpieces

* Steel based tungsten carbide coating workpiece

* Non-metallic materials semi-finishing grinding and finishing grinding, etc.



diamond / cbn wheel

After constant adjustment of formula and technology

We finally successfully developed the first Vitrified Diamond Grinding Wheel for thermal spraying coating industry

diamond / cbn wheel diamond / cbn wheel



Features:

* The bonding strength of vitrified bond to grinding is better than resin bond

* After customized diamond grinding tools with higher diamond concentration, it is less heat and jam generate in grinding

* High grinding efficiency

* Very sharp grinding

* Long lifespan and easy to dress



In terms of the shaping and dressing of the abrasive tools, it is relatively easy to operate (by using diamond dressing tools, to improve work efficiency and save the time of disassembly of the grinding wheel).

It is generally used for semi-finishing grinding, finishing grinding, and forming grinding with large contact surface, etc.

Therefore, vitrified bond is a kind of bond that is increasingly widely used until now.



Resin Bond Grinding Wheel is also mainly used in thermal spraying coating process

diamond / cbn wheel

Features:

* Excellent elasticity and polishing effect

* After forming the abrasive tools, it has good self-sharpening

* Less jam and dress, with highly grinding efficiency

* High finishing of work piece

* Low grinding temperature


TAG:  vitrified diamond grinding wheel vitrified bond thermal spraying coating resinbond
Drawing&Specification

Specification for Vitrified Bond Diamond Grinding Wheel for thermal spraying coating.

1a1 diamond wheel

  Type

 D

X

U

1A1

100

5、10、15、20

3-12

1A1

125

5、10、15、20

3-12

1A1

150

2、3、4、5、8、10、15、20

3-12

1A1

170

14

3-12

1A1

175

10、20

3-12

1A1

200

5、10

3-12

1A1

250

5、10

3-12

1A1

300

10

5-10

1A1

350

10

5、10、30、40、50

1A1

400

10、25

5、10

1A1

500

10

5、10

1A1

620

10

25

1A1

720

10

25
